Description
Advanced Monitoring Solution. The Holley EFI 6.86 Inch Pro Dash provides a comprehensive and customizable platform for monitoring a wide range of engine parameters from Holley EFI systems. Designed for motorsports and performance use, it delivers real-time data at a glance, improving situational awareness and vehicle tuning precision.
Construction and Appearance. This digital dash features a rugged weatherproof aluminum housing with a sleek black finish for durability in demanding environments. It incorporates a high brightness, low glare 6.86 inch capacitive touchscreen with a resolution of 1280×480, ensuring clear and vibrant visuals even in direct sunlight.
Installation. Installation is straightforward with a plug-and-play connection and a comprehensive wiring harness included. Flexible mounting options and hardware are provided for surface or flush mounting, typically requiring no drilling.
Application. Compatible with various Holley EFI systems including Terminator X, HP, Dominator, and Sniper 1 Mizu CAN units. It fits universally but may require some adaptation depending on specific vehicle configurations.
Holley EFI 553-112
CA Residents: WARNING: Cancer and Reproductive Harm
- Customizable With Variety Of Gauge And Indicator Screens
- Displays Any Parameter From Holley EFI System
- Integrated 10-LED Shift Light Included
- Four Programmable LEDs Located At Top Corners
- Screen Size Is 6.86 Inches Diagonal
- 1280×480 Resolution, Low Glare, High Brightness Display
- Capacitive Touch Screen For Easy Operation
- Plug And Play Connection With Holley EFI Systems
- Weatherproof Aluminum Housing With Flexible Mounting
- Includes 34-Pin Connector With 13 Multi-Configurable Inputs
- Inputs Compatible With Various Holley EFI Sensors
- Two Dedicated Speed Inputs For RPM Or Driveshaft Speed
- Four Ground Switched Outputs For Auxiliary Accessories
- Monitors Up To 238 Real-Time Values Such As RPM, TPS, Boost
- Comes Pre-Loaded With 10 Background Skins And Supports Custom Layouts
- Virtual Switch Panel Eliminates External Toggle Switches
- Manual And Auto Brightness Features For Day And Night Viewing
- Built-In GPS With Odometer Function And Included Antenna
- On-Screen Datalog Playback For Reviewing Run Information
- Expandable Storage Via USB
- Capacitive Touch Requires No Stylus
- User Definable Channel Alarms And Warnings
- Includes USB Keyboard And Mouse Functionality For Setup
- Mounting Holes For Surface Or Flush Installation Included
- Compatible With Terminator X, HP, Dominator, Sniper 1 Mizu CAN EFI Systems
- Real-Time ECU Tuning Supported With HP/Dominator ECUs
- Dash Weight Approximately 1.2 Pounds
- Fits Universal; Some Adaptation May Be Required
| Brand | Holley EFI |
| Gauge Type | Multi Gauge |
