Description
HPS 100% marine grade 316 stainless steel T Bolt hose clamps with effective range 3.25″ – 3.58″ (83mm-91mm) perform well in saltwater applications and offer better corrosion resistance than the standard 304 T-bolt band clamp; therefore 316 tbolt clamps are commonly used to provide leak-proof connections on marine engine and exhaust systems. Fits HPS silicone hose with 3″ (76mm) inside diameter. It is recommended that two clamps be used on each end of a wet exhaust installation. Professionals also utilize the high strength 316 T Bolt clamps in applications such as water treatment and sewage systems, military, filter bags, telecommunication devices, sanitary systems, food and pharmaceutical processing equipment. Technical Specification: Effective size range: 3.25″ – 3.58″ (83mm-91mm). SAE # 76. 100% marine grade 316 Stainless Steel Band, Bolt and Nut. High strength with superior welded construction. Meets or exceeds SAE Spec. J1508 for T-Bolt clamps. 3/4″ Band Width. Max. Torque Spec 75 in. lbs.r
- 100% marine grade 316 stainless steel band, bolt and nut. High strength superior welded construction.
- Perform well in saltwater applications and offer better corrosion resistance than 304 T-bolt band clamp. Meets or exceeds SAE Spec. J1508 for T-Bolt clamps.
- Effective range: 3.25″ – 3.58″ (83mm-91mm). SAE # 76.
- Floating bridge and rolled edges to protect soft hoses. 3/4 inch (19mm) band width.
- Maximum Torque Spec 75 in. lbs. Recommed to use two clamps for wet exhaust application.
r
r
r
r
r
rr
Attributes:
r
- r
- GTIN: 00648044880969
- Brand Name: HPS Performance
- Effective Diameter Range: 83mm-91mm
- Recommend to be used on HPS Hoses with these INSIDE Diameter: 3″ (76mm)
r
r
r
r
rr
Extended Information:
r
- r
- Country of Origin: China
- Emissions : Released
- Life Cycle Status: Available To Order
r
r
r
rr
Packing Information:
r
- r
- Quantity of Each: 1
- Package UOM: EA
- Dimension: 4 x 4 x 4 inches
- Weight: 0.32 lb
r
r
r
r
r
