ICON Vehicle Dynamics V.S. 2.5 Series CDCV Front Shock System with Upper Control Arms for 0 to 2-Inch Lift (11-19 Sierra 2500 HD)

Description

Advanced Suspension System. The ICON Vehicle Dynamics V.S. 2.5 Series CDCV Front Shock System with Upper Control Arms for 0 to 2-inch lift enhances driving performance by increasing wheel travel and improving ride quality for heavy-duty trucks. This system delivers vehicle-specific damping and caster correction to optimize both off-road capability and on-road comfort, ensuring superior handling and durability.

_x000D__x000D_

Construction and Appearance. The upper control arms are constructed from CNC bent 1026 DOM steel tubing with a semi-gloss black powder coat finish for enhanced corrosion resistance and strength. The shocks feature 6061 billet aluminum manifolds, a nitrogen-charged monotube design, and precision-machined components designed for durability and heat dissipation.

_x000D__x000D_

Installation. This system requires moderate mechanical skills for installation and does not require drilling. Components are designed to fit specifically with compatible ICON shock absorbers and are sold as a complete assembly for a streamlined installation process.

_x000D__x000D_

Warranty. This product is backed by a comprehensive warranty for peace of mind.

_x000D__x000D_

Application. Designed specifically for 2011-2019 Sierra 2500 HD models, ensuring compatibility with OEM configurations and optimal performance without the need for modifications.

ICON Vehicle Dynamics 78725

CA Residents: WARNING: Cancer and Reproductive Harm

_x000D_
• Take the performance of your 2011-2019 GM HD truck to new levels with the Delta Joint Tubular Upper Control Arm Kit.

_x000D_

• Constructed from CNC bent 1026 DOM steel tubing and powder coated in semi-gloss black for maximum strength and corrosion resistance.

_x000D_

• Engineered with built-in caster correction for optimal alignment specifications and confidence-inspiring handling.

_x000D_

• Provides nearly 50% increased wheel travel when paired with 2.0 or 2.5 Series shock absorbers for superior performance and ride quality.

_x000D_

• Features patented Delta Joint, a high-angle ball joint combining the durability of a ball joint and the performance of a traditional uniball.

_x000D_

• Delta Joint includes zinc-plated housing, tough grease seal, metal-on-metal construction, and greaseable design for longevity and noise-free operation.

_x000D_

• Upper control arms sold only as complete system with ICON shock absorbers for compatibility.

_x000D_

• Includes vehicle-specific 2.5 Series shocks with length and damping tuned for each application.

_x000D_

• Shocks are 100% rebuildable and revalveable, featuring 6061-billet aluminum manifold creating internal bump zone to increase damping force by 20%.

_x000D_

• Features externally adjustable compression damping control valve with 10 levels of compression damping force.

_x000D_

• Includes serviceable dual-stage bushings, CNC machined bushing housings and sleeves.

_x000D_

• Constructed from durable 1026 DOM steel for strength and reliability.

_x000D_

• Features remote reservoir design to improve heat dissipation, reducing shock fade during prolonged use.

_x000D_

• Premium grade 5WT shock oil provides consistent suspension damping across a wide temperature range.

_x000D_

• Nitrogen charged monotube design and one-piece digressive piston with vehicle-specific valving.

_x000D_

• 7/8 inch diameter induction hardened chrome plated shock shaft.

_x000D_

• PTFE lined spherical bearings and application-specific mounting hardware.

_x000D_

• 6061 aircraft grade aluminum CNC machined components and CAD-plated, precision-machined 1026 DOM steel shock body.

_x000D_

• Fits 2011-2019 Sierra 2500 HD models.

_x000D_

Brand	ICON Vehicle Dynamics
Shock Type	Non-Adjustable
Shock Lift Height	0 to 2-Inch Lift
